| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Coslight |
| Model Number: | CPL5000 |
| Minimum Order Quantity: | 50 units |
| Price: | $1,498.00/units >=50 units |
| Packaging Details: | wooden packing |
| Supply Ability: | 50 Unit/Units per Month |
| Power Source: | Other | Battery Type: | Lithium Ion |
|---|---|---|---|
| Inverter Type: | Pure Sine Wave | Controller Type: | NONE |
| Special Features: | Wireless Charging, RV Port, External Battery | Port: | Sz/hk |
| High Light: | Coslight Portable Power Station,5000w Portable Power Station,5000w portable camping power station |
||
|
Models
|
CPL5000
|
|
|
|
Battery
|
Nominal Voltage
|
51.2V
|
|
|
|
Voltage Range
|
45~57.6V
|
|
|
|
Capacity
|
5000WH
|
|
|
|
Max.discharge Rate
|
1C
|
|
|
|
Max.charge Rate
|
1C
|
|
|
|
Battery Type
|
Li-ion(LFP)
|
|
|
AC Output
|
Rated Power
|
5000W
|
|
|
|
Surge Power
|
10000W
|
|
|
|
Output Voltage
|
220/230/240Vac
|
|
|
|
Output Current
|
22A
|
|
|
|
Rated Frequency
|
50/60Hz
|
|
|
|
VTHD
|
＜3%
|
|
|
|
Output Wave
|
Pure Sine Wave
|
|
|
|
Output Type
|
Euro Round AC Socket×2 ; 48Vdc Socket×1(Anderson 100A)
|
|
|
|
Max. Efficiency
|
93%
|
|
|
AC Input
|
AC Input Voltage Range
|
170~280Vac
|
|
|
|
AC Input Frequency
|
50/60Hz
|
|
|
|
Max AC Charge Current(Battery)
|
30A(0~60A Adjustable)
|
|
|
|
Max. Efficiency
|
93%
|
|
|
PV Input
|
Max. PV Power(Recommended)
|
4000W
|
|
|
|
Max. PV Voltage
|
450V
|
|
|
|
MPPT Range
|
120V~430V
|
|
|
|
Max PV Charge Current(Battery)
|
80A
|
|
|
Operating Conditions
|
Operating Temperature
|
0~55℃
|
|
|
|
Storage Temperature
|
-15℃~60℃
|
|
|
|
Humidity
|
5%~95%
|
|
|
|
Cooling Strategy
|
Fan
|
|
|
|
Weight
|
78kg
|
|
|
|
Dimension [W x H x D]
|
TBD
|
|
|
|
Packing
|
wooden case
|
|
|
|
Packing Dimension [W x H x D]
|
TBD
|
|
|
|
Enclosure Protection Rating
|
IP20
|
|
|
|
Communication
|
WIFI/RS485
|
|
|
|
Warranty
|
2 years
|
|
