Electric Vehicles 12v 100ah Lifepo4 Lithium Batteries Submarine

Basic Information
Place of Origin: guangdong province, China
Brand Name: Coslight
Certification: CE
Model Number: 12v 100Ah
Minimum Order Quantity: 100 pieces
Price: negotiable
Packaging Details: Wooden package
Delivery Time: 10-15days
Payment Terms: T/T
Supply Ability: 5000pcs per month
Product Name: Lead-acid Replacement Battery Voltage: 12.8 Voltage
Cycle Time: More Than 2500 Times Brand: Coslight
OEM: Acceptable Warranty: 5 Years
Deliver Way: Sea, Air & Door-to-door Capacity: 100Ah
High Light:

12v 100ah Lifepo4 Lithium Batteries

,

Submarine Lifepo4 Lithium Batteries

,

Submarine 24v 100ah Lithium Battery

Electric Vehicles 12v 100ah Lifepo4 Lithium Batteries Submarine






 Product Information


Electric Vehicles 12v 100ah Lifepo4 Lithium Batteries Submarine 0

Quick Detail:



  1. Battery Size:12V
  2. Certification: CE
  3. Model Number:12.8v lithium battery
  4. Place of Origin: Guangdong, China
  5. Type: lithium battery
  6. Size: customized
  7. Compact Designed: Built-in BMS
  8. Box Material: waterproof ABS-plastic case
  9. Certificate: CE, Rohs, UN38.3, MSDS
  10. Keywords:12v 100ah lithium battery
  11. Advantage: high cycle times
  12. Warranty:1 years







Description:

The deep cycle 12v modularized are compactly designed with ABS plastic box and built-in BMS to protect the battery from over-charge, over-discharge, over-current, over-voltage, over-temperature, and short circuit.

BMS
The BMS helps to ensure safe and accurate running.
Over charging
Over discharging
Over current
High temperature
Short circuit
Thermal shock
NO fires
No explosions



Applications:

1.Longer battery life – 5000times life cycle @60%DOD, 5 times more than lead acid batteries
2.Low self-discharge <3.5% per months; Steady discharge and charge performance.
3.Wide temperature performance
4.Short circuit protection; Over charge and over discharge protection; Over current protection
5.Easy carrying and installation - can be carried and installed in any direction
6.Fast charging - about 2~3 hours to be fully charged
7.Lighter weight - 1/2~1/4 in weight compared to LA batteries
8.Better safety - mild warm, no explosion and firing, free of leakage UPS

Electric Vehicles 12v 100ah Lifepo4 Lithium Batteries Submarine 1





Specifications:

ELECTRICAL SPECIFICATIONS MECHANICAL SPECIFICATIONS
Nominal Voltage 12.8 V Length 330± 2 mm
Nominal Capacity @ 0.2C 100 Ah Width 172 ± 2 mm
Energy 1KW Height 215± 2 mm
Resistance 50mΩ Weight 10Kg
Cycle Life 2000+cycle times @ 1C 80% DOD Case Material ABS
Efficiency 99% Terminal T2
Self Discharge <3% per Month Enclosure Protection IP65
Maximum Modules in Series/Parallels 4S1P Length 330± 2 mm





CHARGE & DISCHARGE SPECIFICATIONS

Monthly Self Discharge

Less than 2%

Efficiency of Charge

100% @ 0.5 C

Efficiency of Discharge

96 - 99% @ 1 C

Charge Voltage

14.2 ± 0.2 V

Charge Model CC & CV

0.2C to 14.6 V ,

then 14.6V, charge current to 0.02C

Standard Charge Current

1.4 A

Max. Charge Current

100 A

Max. Continuous Discharge Current

100 A

Peak Discharge Current

14 A (3S)

BMS Discharge Cut-off Voltage

10 V

Charge Temperature

0~45 ℃

Discharge Temperature

-20℃ to 60 ℃

Storage Temperature

-20℃ to 45 ℃






FAQ

Q1: Are you a factory or trading company?
A: We are a professional battery manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients, which can produce by your samples or technical drawings. We can build the molds and fixtures.

Q2: Where can I get the price?
A: We will offer you the best quotation in 12 hours after we get the product specifications such as voltage capacity application etc.

Q3. What are your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q4. Do you test all your goods before delivery?
A: Yes, We have a professional QC team to make sure that the product in good condition before sending out the goods.

Q5: How do you make our business a long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
