| Place of Origin: | GuangDong.China |
|---|---|
| Brand Name: | Coslight |
| Certification: | UL, CE, FCC, RoHS, Un38.3, CB, IEC62133, MSDS |
| Model Number: | Portable power station |
| Minimum Order Quantity: | 30 pcs |
| Price: | Negotiable |
| Packaging Details: | Wooden Box |
| Delivery Time: | 30-45 working days |
| Payment Terms: | T/T |
| Supply Ability: | 5000 pcs/month |
| Type: | LiFePO4 | Warranty: | 3years |
|---|---|---|---|
| Brand: | Coslight Or OEM | OEM/ODM: | Support Customize |
| Delivery: | Sea, Air Or Express | Application: | Emergency、Outdoor Energy |
| High Light: | OEM Outdoor Lifepo4 Portable Power Station,OEM Coslight Lifepo4 Portable Power Station,OEM Outdoor Lifepo4 Power Generator |
||
Coslight Outdoor Lifepo4 Portable Power Station Lifepo4 Power Generator
Product model JL-1000
Battery capacity 1008WH (3.2V/315000mAh)
Output power rated 1000W Peak 2000W (long term load 800W)
Input voltage 110V/50 or 220V /60Hz optional (built-in charger about two hours of charging 80-100%)
The output voltage is 220V 50Hz or 110V 60Hz
Dc output 12V smoke port /8A, PD65W (two), QC3.0 two, 5V/3A two, two of which share one output
The LED 5 w
Shared solar and vehicle-mounted charging port 12V/3-4A vehicle-mounted charging, solar charging power 240W (voltage range: 12-36V)
Output waveform ac pure sine wave inverter
UPS switchover takes 5-10 ms
Lithium iron phosphate battery cycle life 2000 times
Weight 11.2kg net weight 12.5kg after packing
Length 30.9* width 21.5* height 21.9cm
Color Silver body black panel Gray body yellow panel
Function description of front panel
Keys on the front panel are display keys; press the keys to display the electric quantity, power. Functions displayed by LED screen include input information, output information, capacity information, while the running information bar includes overcharge, over discharge, over-temperature.
|
NO. |
Name |
function |
|
1 |
charge indicator |
Respectively"DC->"/"CAR->"/"PV->",Represents different charging modes. |
|
2 |
Electricity Icon |
The battery power is displayed in six cells, and the charging will indicate the battery power by running horse. |
|
3 |
Battery Indicator |
According to the percentage, the battery power is 0%-100%. |
|
4 |
Residual time indication |
"Time To Full"Display full remaining time,"Time To Empty"Display the remaining time of emptying,The corresponding number will be below+H or M Represents the remaining hours and minutes. |
|
5 |
Total power indication |
number+Wcombination,Polling shows the total power of charging and discharging, |
|
6 |
|
Constant current output |
|
7 |
Interface status indication |
DC,CAR,USB-A,USB-C,AC,Light,Represents the corresponding interface state. |
|
8 |
Car Start State Indicator |
The three right-most display combinations, Car-Start/Car-Start Failed/Car-Start Completed, represent that the car is starting and charging, starting and charging fails, starting and charging is completed. |
Function description of front pane
|
NO. |
Function description |
||
|
1 |
Display screen |
7 |
QC3.0 output port |
|
2 |
DC switch |
8 |
USB-C PD3.0 60W output port |
|
3 |
DC5.5 12V output port |
9 |
USB 5V2.4A output port |
|
4 |
LED Floodlight |
10 |
AC switch |
|
5 |
Cigarette lighter port |
11 |
AC output port |
|
6 |
DC input port |
12 |
LED switch |
Application:
Q1: Are you a factory or trading company?
A: We are a professional battery manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for clients, which can produce by your samples or technical drawings. We can build the molds and fixtures.
Q2.Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q3: Where can I get the price?
A: We will offer you the best quotation in 12 hours after we get the product specifications such as voltage capacity application etc.
Q4. What are your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q5. How about your delivery time?
A: Generally, it will take 20-30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q6. Do you test all your goods before delivery?
A: Yes, We have a professional QC team to make sure that the product in good condition before sending out the goods.
Q7: How do you make our business a long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
